The next generation of sound

Featuring a flagship DAC chip and USB controller, the SMSL VMV D1se2 is a desktop digital-to-analog converter that’s ahead of the pack. Its revolutionary D/A chip integrates 8 DACs, while its USB controller supports the absolute highest audio files, providing jaw-dropping fidelity and unparalleled dynamic range.

ESS ES9039MSPRO DAC chip

The VMV D1se2 uses the fully-redesigned ESS flagship D/A chip: the ES9039MSPRO. With a 32-bit, 8-channel system, this audio powerhouse combines 8 integrated DACs using the cutting-edge Hyperstream IV architecture for unprecedented dynamic range and built-in MQA hard decoding.

Bluetooth 5.0

Stream your favorite tracks from your phone, tablet, or other streaming device with ease, and enjoy the unparalleled sound quality of top-tier Bluetooth codecs like LDAC and aptX HD.

XMOS XU-316 USB controller

Hear every detail in your music, from the subtlest notes to the most powerful bass lines. Thanks to a 3rd generation USB controller, the VMV D1se2 is compatible with the highest quality song files available, including DSD512 and 32-bit/768kHz PCM.

Distortion as low as 0.00005%

With 11 high-end dual op-amps and a linear British-made NORA-TEL toroidal transformer, the VMV D1se2 provides exceptional audio clarity that will make you feel like you're in the room with the performers.

Product highlights

• MQA certification
• MQA-CD certification
• ESS ES9039MSPRO D/A chip
• Distortion as low as 0.00005%
• Eight-channel parallel circuit
• XMOS XU316 USB controller
• DSD512, PCM 32-bit/768kHz
• Linear power supply
• Full-function remote control

Specs

• Inputs: USB, Optical, Coaxial, Bluetooth, I2S
• Outputs: RCA, XLR
• Line out amplitude
• XLR: 5.2Vrms
• RCA 2.5Vrms
• THD+N: 0.00005% (-125dB)(Unweighted)
• Dynamic range
• XLR: 133dB
• RCA: 128dB
• SNR
• XLR: 133dB
• RCA: 127dB
• USB transmission: USB 2.0
• USB compatibility: Windows 7, 8, 8.1, 10, Mac OS X 10.6 or later, Linux
• MQA decoder: USB: optical, coaxial
• MQA-CD decoder: Optical, coaxial
• Max sampling rates at bit widths
• USB: PCM 32-bit/768kHz, DoP256
• DSD: 22.5792MHz
• Optical, coaxial: 24-bit/192kHz, DoP64
• LDAC: 24bit/96kHz
• aptX-HD: 24bit/48kHz_576kbps
• aptX: 16bit/44.1kHz_352kbps
• SBC: 16bit/44.1kHz_328kbps
• AAC: 16bit/44.1kHz_320kbps
• Bluetooth version: 5.0
• Power consumption: <10W
• Standby power: <0.5W
• Size: 8.2” x 6.6” x 1.5” (210mm x 170mm x 39mm)
• Weight: 3.59lb (1.63kg)

What’s included

• SMSL VMV D1se2 DAC
• Remote control
• Adjustable feet x4
• Warranty card
• Manual
