Next Gen Specs

With distortion as low as 0.00009% and a dynamic range of 126dB, the E50 is a desktop DAC that’s light on bells and whistles but heavy on performance.

ES9068AS DAC chip

The E50 uses the latest ESS ES9068AS DAC chip, a 32-bit, 2-channel D/A converter designed for audiophile-grade applications. Using the critically acclaimed ESS patented HyperStream II architecture, QUAD DAC technology, Time Domain Jitter Eliminator, and advanced SABRE HiFi technology, the ES9068AS delivers world-class audio performance.

DSD512 & 32-bit/768kHz PCM via USB

The E50 offers top-of-the-line decoding via USB with the XMOS XU216 2nd generation 16-core processor. It supports 32-bit/768kHz PCM, DSD512 native, and MQA full decoding. Windows 10, Max, Linux, iOS, and Android users can plug-and-play the E50 without installing drivers. Only Windows ASIO applications require a driver.

24-bit coax and optical

Get HiFi decoding not only with the USB input but with the coax and optical as well. The E50’s coax and optical inputs support 24-bit/192kHz PCM, DSD64 (DoP), and MQA rendering.

Ultra-portable 5V power supply

The E50 requires only a 5V power supply, meaning you can power it with the USB port of your PC or Mac, or a portable phone charger. At only six inches on its longest side, you can slip it into your suitcase, backpack, or briefcase and use it on trips.

Smart on/off

With an auto on/off function for all inputs, the E50 is a true “set it and forget it” DAC. It automatically turns on and decodes whichever input is receiving a signal, and when it hasn’t received a signal for sixty seconds, it automatically turns off.

Selectable output port

The E50 features an output selection button with options for “TRS only,” “RCA only,” and “TRS + RCA.” This last option lets you run cables to two different destinations, such as a headphone amp and powered monitors, and listen to either without having to do the cable shuffle.

Doubles as a preamp

If you only need a DAC to use with powered speakers, you can skip buying an amp completely. That’s because the E50 has a preamplifier mode. WIth this mode selected, you can control the output volume with the remote control.

Product highlights

• ESS ES9068AS DAC chip
• XMOS XU216
• 0.00009% THD+N
• DSD512 Native
• PCM 32-bit/768kHz
• Full MQA decoding via USB
• RCA & balanced TRS outputs
• Ultra-low noise preamp
• Remote control

Specs

USB in

• PCM: 44.1kHz-768kHz/ 16bit-32bit
• DSD: DSD64-DSD512 (Native), DSD64-DSD256 (DoP)
• MQA: Full decoding

Coax/optical in

• PCM: 44.1kHz - 192kHz/ 16bit-32bit
• DSD: DSD64 (DoP)
• MQA: Renderer decoding

Single-ended input decoding parameters (USB in @96kHz):

• THD+N (A-wt): <0.0001% @1kHz
• THD (No-wt 90kBw): <0.0003% @20-20kHz
• SNR (A-wt): 124dB@1kHz
• Dynamic range (A-wt): 124dB@1kHz
• Frequency response
• 20Hz-20kHz(±0.1dB)
• 20Hz-40kHz(±0.3dB)
• Output level: 2Vrms @0dBFS
• Noise (A-wt): <1.3uVrms
• Crosstalk: -130dB @1kHz
• Channel balance: 0.3dB
• Output impedance: 20Ω

Balanced input decoding parameters (USB in @96kHz):

• THD+N (A-wt): <0.00009% @1kHz
• THD (No-wt 90kBw): <0.0003% @20-20kHz
• SNR (A-wt): 126dB@1kHz
• Dynamic range (A-wt): 126dB@1kHz
• Frequency response
• 20Hz-20kHz(±0.1dB)
• 20Hz-40kHz(±0.3dB)
• Output level: 4Vrms @0dBFS
• Noise (A-wt): <2.3uVrms
• Crosstalk: -139dB @1kHz
• Channel balance: 0.3dB
• Output impedance: 100Ω

Physical dimensions: 6.1 x 5 x 1.6” (15.5 x 12.9 x 4.1cm)

What’s included

• TOPPING E50
• Remote control
• USB cable
• DC cable
• User manual
• Warranty card

What pairs well

• TOPPING L50 Headphone Amp
